APK 165 - KIT 2Way AP 1 AP 6.5 Grilles

Two way system features AP 1 tweeter and AP 6.5 woofer. APCX TW crossover features a two-position level selector providing the ability to adapt its response to its two main applications: 2dB if installed behind the OEM grille, 0dB for an A-pillar installation without additional grilles between the tweeter and the listener. To ease the installation in OEM placements the woofers are equipped with high current fast-on terminals with double contact on positive and negative poles for high flexibility and quick connection.

Features -
AP 1 tweeter with 26 mm diameter diaphragm combined with a wide-roll surround provides maximum efficiency and reduced resonance frequency.
AP 1 tweeter with acoustic lens designed to compensate for and fine tune the in-car frequency response anomalies in the 10kHz - 13kHz bandwidth caused by restrictive OEM grilles in critical OEM placements.
APCX TW very compact tweeter passive crossover optimised for OEM Integration featuring an attenuation switch (0 dB, 2dB) to tune the in-car response according to different installation conditions.
Passive crossovers are supplied with “OEM Integration compliant” fast-on connectors. The ends, different in each of the two poles, eliminate any possible connection errors and speed up the required installation time.
AP 6.5 woofer with 32 mm pure copper voice coil, for high power handling and outstanding low frequency control.
AP 6.5 woofer with water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel R&D Scan Vibrometer.
AP 6.5 woofer with reduced mounting depth, providing ease of installation in OEM placements.
AP 6.5 woofer with TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow “Triple Wave” profile, for maximum excursion linearity.

• Is Discontinued By Manufacturer ‏ : ‎ No
• Product Dimensions ‏ : ‎ 16.54 x 9.76 x 5.28 inches; 3.53 Pounds
• Date First Available ‏ : ‎ July 30, 2014
• Manufacturer ‏ : ‎ Audison
